Description
- Robust industrial fan unit heater for floor, wall, or ceiling mounting
Flanged heating element
Application
- Heating fluids in hydraulic, lubrication, and heat transfer installations, water in storage tanks and systems, and chemical fluids
Design
- DIN 2527 steel flange, PN 16 to PN 100
- U-shaped tube elements, installation length up to 3500 mm, in steel, titanium, and various stainless steel
- also with exchangeable elements
- nominal width up to DN 500 mm
Thermostat 0 to 120°C, differential gap 3 K, switching power 16 A to 400 V, 1 pin, lacquered steel hood, IP 30 or IP 65 protection system
TŨV inspection possible
Complete continuous-flow heaters are also available
- Spesification
● Oil heating
Length (mm)/Power Watt
450/2000
450/3000
870/4000
670/4500
670/6000
870/8000
670/9000
870/12000
670/18000
670/27000
870/24000
870/36000
● Water heating
Length (mm)/Power Watt
400/6000
400/9000
770/12000
610/13500
610/18000
770/24000
610/27000
770/36000
610/54000
770/72000
